Secure choice

Comar Architectural’s 5P.i VSW has just passed BS7950 enhanced security for windows.

With its slim sightlines, the Comar 5P.i VSW can be manufactured to fit openings upwards of 500mm wide and, depending on wind loading, up to 2800mm high. Using re-designed Caldwell Torso Balances, unique to the Comar 5P.i VSW, the window provides even more reliability and security features, such as sash locks with a concealed locking mechanism so the window can provide long lasting smooth operation as well as hidden locking. The sash lock includes a double keep which maintains security as well as providing trickle ventilation.

Internally beaded, the Comar 5P.i VSW provides a neat exterior finish and can be coupled to other window configurations to create larger composites. Integration has also been catered for with dedicated profiles to allow incorporation into Comar 2 window walling. Both sashes of the Comar 5P.i VSW have been designed to slide smoothly into an open position and the sashes to discretely combine to provide maximum air change. However, there are times when this is not required and Comar 5P.i VSW can be fitted with a lockable restrictor at 100mm increments. To ensure the continued long term visual appeal and maintenance of the Comar 5P.i VSW, both sashes can be tilted for cleaning.

Weather performance is assured with brush and bubble seals to the whole perimeter of each sash, passing the requirements BS6375. An additional buffer seal is incorporated into the outer frame to increase weather resistance. To comply with future demands, the Comar 5P.i VSW has a range of gaskets and beads which allow glazing from 22mm-32mm.

The Comar 5P.i VSW frames are constructed with mitre joints with an inserted spring-loaded Monticelli cleat. The slide and tilt function of both sashes is created through Torso Balances which are designed to suit the window size and glass specified.
